Increase your binary method flexibility. The Thermo Scientific Dionex UltiMate HPG-3400SD Standard Binary Pump allows four different mobile phases, two at a time. Thermo Scientific SmartFlow technology delivers pulse-free flows without a damper to ensure precise retention times. With support for pressures up to 62MPa (9,000 psi/620 bar) at flow rates up to 10mL/min., UltiMate 3000 SD pumps excel in standard LC applications and offer full compatibility with fast UHPLC separations, including short sub-2 µm particle columns for faster analysis and lower solvent consumption.
This pump is recommended for use within the UltiMate 3000 Binary Standard system. The HPG-3400SD pump is ideal for routine analyses with an added measure of flexibility using conventional LC and high-throughput LC in the pharmaceutical, food and beverage and environmental industries.
UltiMate 3000 Standard SD and Rapid Separation (RS) pumps and system configurations provide similar gradient delay and extra-column volumes. This simplifies the method transfer between method development labs commonly using UHPLC pumps and QC and production labs with their standard LC pump setups.
Features:
- Serial dual-piston operating principle, high-pressure gradient proportioning
- Wide operating flow rate range from 100µL to 10mL/min. with high flow rate accuracy
- Support of operating pressures of up to 62 MPa (9,000 psi/620 bar)
- Thermo Scientific SmartFlow technology to automatically compensate for compressibility; no manual solvent setting needed
- Large selection of mixing volumes to perfectly balance gradient delay volume with mixing efficiency
- Active rear-seal wash and floating pistons to maximize seal lifetime and pump uptime
