This Dionex UVD 340U UV/VIS Detector is in great condition.It has been tested at SpectraLab Scientific.
A 90 day warranty is provided.
We have special expertise on analytical equipment. We encourage you to contact us to speak with one of our expert and professional team members.
Thanks for looking and we look forward to hearing from you!
Specification | |
Wavelength Range | 200–595 nm, programmable |
Noise | < ± 5 µAU (dry cell, 254 nm,8 nm, 1 s) |
Drift | < 500 µAU/h |
Wavelength Accuracy | ± 0.75 nm (UV), ± 1.5 nm (Vis) |
Bandwidth | 1.9–400 nm, programmable |
Linearity | ≤1% at 1.5 AU |
Measuring Range | 0–2 AU |
Time Constant | 0.1–4.0 s, programmable |
Power-up Wavelength Verification | Automatic via internal holmiumoxide filter |
Wavelength Calibration | Automatic or on demand; over the entire
wavelength range |
Optical Bench | Photodiode array bench withoutmoving parts |
Pixel Resolution | 1.9 nm (UV), 3.3 nm (Vis) |
Lamp | Deuterium Lamp |
Standard Cell | 10 µL, 9 mm, 10 MPa (1450 psi) |
Biocompatible Cell (optional) | 10 µL, 9 mm, 10 MPa (1450 psi) |
Preparative Cell (optional) | 6 µL, 2 mm, 10 MPa (1450 psi) |
Micro Capillary Cell (optional) | 0.14 µL, 8 mm, 40 MPa (5800 psi) |
