The UltiMate WPS-3000SL Semi-Preparative Autosampler performs reliable, accurate and preciselarge-volume injections for purifying compounds in the microgram to lower milligram range. It is an essential part of the Thermo Scientific UltiMate3000 Semi-Preparative System.
Performance
- Pulled-loop injection principle for full- and partial-loop injections
- Wide injection volume ranges from 1 to 10μL in partial-loop and 20μL in full-loop mode, or 10 to 100μL and 200μL, respectively.
- Low sample carryover (typically < 0.01%).
- Built-in eluent preheating for improved chromatographic reliability at high temperatures.
- Patented, liquid-based temperature control for efficient heat extraction, protecting thermally sensitive samples.
- Accurate and precise column temperature control (±0.1°C measured in the sample) to qualification standards within pharma laboratories.
Ease of Use
- The Thermo Scientific Viper Fingertight Fitting system allows easy switching of injection volumes and sample loops.
- All fluidic components are accessible from the front.
Specifications:
| For Use With (Equipment) | UltiMate 3000 Semi-Prep System |
|---|---|
| Injection Cycle Time | <20 sec. |
| Injection Volume Precision | <0.3% |
| Injection Volume Range | Settable range: 0.01 to 2500 µL Recommended range: 100 to 2000 µL Optional: 10 to 1000 µL |
| Injection Type | Split Loop |
| Sample Capacity | 3 racks or well plates |
| Max. Pressure | 620 bar/9000 psi |
| Biocompatible Version | No |
| Linearity | >0.9999 |
| Voltage | 100 to 120 V |
| Weight (Metric) | 23 kg |
| Description | WPS-3000 SL Semi-Preparative Split-Loop Well Plate Autosampler (Discontinued) |
| Carryover | <0.004% |
| Unit Size | Each |
