Set includes:
- Titramax 1000 Platform Shaker 544-12200-04-3
- Incubator 1000 Heating module 549-90020-00-3 (German ver. “Inkubator 1000,” “Heizmodul”)
- Flat hood (163 mm height) 549-90040-00-1
General Description
The largest model of the Titramax series contains all the features of the Titramax 100. With a storage capacity of up to six multi-well plates, a higher number of samples can be processed. The option to integrate the Titramax 1000 into the modular incubation system also allows temperature-controlled processes to be carried out without problems. With this model, easy loading and removal of the plates can be carried out comfortably due to the recess and the spacings in the rubber mat.
The Incubator 1000 is an unique, modular system lets you do it all: mixing, shaking, and tempering – all without the need for an additional steaming cabinet.
Product Features
- Use of 6 microtiter plates increases throughput by 50%
- 1.5mm vibration orbit performs gentle mixing with best results using small sample volumes
- Medium-sized model and accepts load capacities of 5kg
- Model is suitable for the modular incubator system and is recommended for applications which require variable temperature control of up to 65°C
Product Specifications
| Motion | Vibrating |
| Rotation speed range | 150 – 1,350 rpm |
| Operating Mode | Timer or Continuous |
| Orbit / Stroke | 1.5 mm |
| Timer< | Yes |
| Power input | 31 W |
| Platform size | 290 x 258 mm |
| Max. Load | 5 kg |
| Dimensions | 13x15x6 in |
| Power | 100-120V, 50/60Hz, 50va |
| Weight | 18 LBS |
