These small, reliable tube furnaces meet the specific needs of educational, governmental, and industrial laboratories. Choose from furnaces with single set point or 16-segment programmable controllers.
All models feature microprocessor-based, self-tuning PID control to prevent overshooting of set temperature. As a safety precaution, power to the heating elements is cut off when the chamber temperature exceeds the set temperature or when the door is opened. Overtemperature protection is adjustable—set according to your application. The LED lets you view set temperature and actual temperature simultaneously.
Split hinge design permits convenient placement of the process tube (process tube not included—order separately). Chamber is insulated with energy-efficient Moldatherm for quick heat up and cool down rates.
Min Temperature (° F) | 212 |
Max Temperature (° F) | 2012 |
Min Temperature (° C) | 100 |
Max Temperature (° C) | 1100 |
Temperature Uniformity | ± 1°C over 2-3/16\” segment; ± 3°C over 3-5/16\” segment |
Overall Width (in) | 11 |
Overall Height (in) | 15 |
Overall Depth (in) | 16 |
Overall Width (cm) | 27.9 |
Overall Height (cm) | 538.48 |
Overall Depth (cm) | 40.6 |
Control Type | 16-segment |
Power (VAC) | 120/240 |
Power (Hz) | 50/60 |
Heater Wattage (watts) | 800 |
Process Tube OD (in) | 1 |
Process Tube OD (mm) | 25 |
Process Tube Length (in) | 12 |
Process Tube Length (cm) | 30.5 |
