Thermo Scientific Vanquish Diode Array Detector VC-D11-A Rev. 01
Get the best performance, reliability, and flexibility in HPLC and UHPLC detection with Thermo Scientific Vanquish Diode Array Detector (DAD). These detectors offer excellent linearity and optimized noise performance, and feature an ultra-wide dynamic range to allow detection of highly concentrated main compounds alongside trace-level impurities.
Description | Vanquish Diode Array Detector CG |
Data Collection Rate | Up to 125 Hz |
Detection Mode | UV-vis Detection (Up to 8 Channels) |
Detector Type | Single-Beam |
Type | Diode Array Detector |
PC Connection | USB 2.0; 3-port HUB to connect additional Vanquish modules |
Wavelength Range | 190-800 nm |
Dimension | 159 mm × 420 mm × 620 mm (6.3 in. × 16.5 in. × 24.4 in.) |
Weight (Metric) | 16 kg |
Voltage | 100-240 V AC, 50/60 Hz, max. 250 W/255 VA |
