Compact stirrers with a ceramic glass plate provide excellent chemical resistance. Units feature digital error code display, a ‘hot’ top indicator to warn users that surface is hot, a fixed safety circuit that shuts off the heater if temperature rises above 550 °C, and three operating modes to choose from (standard, safe and adjustment protection). Stirrers have a speed display scale and optional capability to connect directly to a PT1000 temperature sensor; when using this functionality, control accuracy in the medium is ±0,5 °C.
Features:
- Exact temperature setting via digital potentiometer
- Simultaneous digital display of target and actual temperatures via LCD display
- Display of actual temperature value in medium with 0,1 °C resolution when using PT1000 temperature sensor
- Stirrer can be controlled using two microcontrollers
Specifications:
Model | VMS-C10 Advanced |
Max. stirring capacity H₂O (l) | 15 |
Speed range (min-1) | 100 – 1500 |
Temperature range (°C) | 50…500 |
Heat output (W) | 1500 |
Power input/output (W) | 15/1,5 |
Plate material | Glass-ceramic |
Plate dimensions (mm) | 260×260 |
W×D×H (mm) | 300×415×105 |
Weight (kg) | 6 |
