To ensure optimal retention time precision for separations below, at, or above ambient temperature, a Dionex thermostatted column compartment is an essential module for every UltiMate 3000 LC. The addition of built-in, easily accessible valves extends the flexibility and performance options of the LC system. Features like the column identification system and System Wellness simplify method documentation and improve regulatory compliance.
Specifications
Type | Specifications |
---|---|
Temperature Range | 5 ̊C to 85 ̊C(maximum 18 ̊C below ambient) |
Temperature Accuracy | ±0.5 ̊C |
Temperature Stability | ±0.1 ̊C |
Temperature Precision | ±0.1 ̊C |
Column Capacity | Six columns; maximum 30 cm |
Heatup/Cooldown Time | Typically 15 min from 20 ̊C to 50 ̊C Typically 15 min from 50 ̊C to 20 ̊C |
GLP | Dionex AutoQ routines for Instrument Qualification Column Identification System for four columns |
PC Connection | USB |
Inputs/Outputs | Two digital inputs Two relay outputs |
Dimensions | 17 x 42 x 51 cm |
