Shimadzu Nexera X2 UHPLC System

Shimadzu Nexera X2 UHPLC System
Item ID:


Condition: Refurbished

Availability: In Stock

Manufacturer: ShimadzuPrice:

Request Quote/ Offer

Warranty Included, Onsite/ Remote Installation and Training Available


CAN/US: 3-5 business days
International: 5-10 business days

For assistance and further information:

Toll Free: 1-866-777-3688
Tel: 905-946-8066

Spectralab is your one stop shop for all your analytical laboratory needs!

Your source for


and Spectralab Scientific



We will match our competitor's price!

To Sell, Trade in, or Service Your Equipment

The Shimadzu Nexera X2 is a flexible system design achieves a true fusion between UHPLC and HPLC technologies, enabling the Nexera X2 to be used for a much broader range of applications. This UHPLC system not only offers maximum speed, sensitivity, resolution, stability, and reliability, it also features a revolutionary i-PDeA separation technology and an i-DReC function that extends the dynamic range so that both concentrated and trace components can be quantitated simultaneously.

System Includes:

  • Prominence SPD-M20A or Nexera X2 SPD-M30A Photodiode Array Detector
  • 2x Nexera X2 LC-30AD Liquid Chromatograph
  • CBM-20A Communications Bus Module
  • Nexera X2 SIL-30ACMP Autosampler
  • Nexera X2 CTO-30A Column Oven
  • PC with Data


Degassing Unit 3 or 5 Lines (Volume 400 μL)
Flow rate range 0.0001 to 10 mL/min
Flow rate precision No more than 0.06% RSD or 0.02 min SD, whichever is greater
Gradient type High-pressure / low-pressure mixing gradient
Gradient / concentration precision ±0.5% (specified conditions)
Maximum pressure 130 MPa (0.0001 to 3 mL/min)
80 MPa (3.0001 to 5 mL/min)
22Mpa (5.0001 to 10 mL/min)
Injection method Needle-in-flowpath
Injection volume accuracy ±1% (at 50 μL injectiong, n = 10)
Injection volume range 0.1 to 50 μL (Option: 0.1 to 100 μL)
Injection volume reproducibility RSD: 0.2% maximum (at 10 μL)
Samples capacity Sample plate: 324 (1.5 mL), 576 (96 well MTP/DWP Plates), 2304 (384 well MTP/DWP plates)
Control plate: 10 (1.5 mL)
Sample cooler Block cooling/heating, used together with defumidifying function
4 to 40°C
Oven Capacity Up to 2 – 150 mm columns
Temperature control range Room temperature ± 5 to 150°C, Setting range 4 to 150°C

Request Quote:

*We do not share your information*

Address (City, State)
Email Confirmation
Your Budget/ Offer

Our refurbished instruments are tested and repaired to meet factory specifications. We follow Installation Qualification, Operational Qualification, and Performance Qualification protocols (IQ, PQ and OQ).

Our team of skilled technicians are experts at fixing analytical instruments. We have been working with Agilent, Waters, Perkin Elmer, Sciex, Shimadzu, and Thermo instruments for many years. We are constantly updating our knowledge with the latest technology and information to enable us to deliver the best support in the industry. We provide value added support and qualification/validation with all our instruments. We endeavor to develop strategic partnerships with our clients so that they consider our team as an extension of their employees. We are an affordable alternative to many normally expensive business projects.

Warranty and Support
We offer warranty on all refurbished instruments. Warranty starts at 3 months, with the option to extend the period. While your instrument is on warranty, we will provide Email ( and phone support and troubleshooting if you require assistance. If there is ever anything wrong with the equipment, we will replace it. Warranty begins from the date your equipment is successfully delivered. Any issues that occur during warranty should be reported immediately, describing the issues in as much detail as possible. Do not attempt to repair the equipment or involve a 3rd party without our express permission – this will result in voiding our warranty.

We will match our warranty duration with our competitors.

Installation and Training
If you purchase equipment from Spectralab Scientific, we offer installation and familiarization by our service technicians for an additional fee. If the instrument is particularly complicated, we highly recommend this service. If you’ve purchased less-complex equipment from us that you would like to install yourself, we can provide Team Viewer, email, or telephone support for no additional cost.

Large Inventory
We have a large inventory of equipment, components and parts in stock. You can find all the equipment you need for you lab in our store, as well as mix and match components for your systems.

International Shipping
We have sufficient export experience, including professional packing and proper documentation. Complementary shipping and handling can be applied upon immediate purchase. We include customs fees, brokerage, and duties for shipping to the US.

Price Matching & Discounts
Purchasing our refurbished instruments can save you anywhere from 30% to 90% compared to purchasing brand new. We will try to match or beat any price from our competitors, so feel free to inquire! Complementary shipping and handling can be applied upon immediate purchase.
